Built-In Test (BIT) SDK¶

Overview¶

The Built-In Test (BIT) SDK is a comprehensive testing solution for Linux embedded systems. It provides three types of automated tests:

PBIT (Power-On Built-In Test): Hardware validation tests run once at system startup
CBIT (Continuous Built-In Test): Ongoing system health monitoring at configurable intervals
FBIT (Factory Built-In Test): Manufacturing and production validation tests

Key Features¶

Dynamic Plugin Architecture: Tests are loaded as shared libraries (.so files)
Configuration Generation: bit-learn tool automatically detects hardware and generates configs
Hardware Discovery: Auto-detects CPUs, disks, network interfaces, USB/PCI devices, sensors
Test Inspection: bit-inspect tool provides detailed test information
Systemd Integration: Run as a system service with bit_manager
Extensible: Create custom tests using the test_template as a starting point

Quick Start¶

# Build the project
cargo build --release

# Generate configuration files for your system
BIT_CONFIG_PATH=/etc/bit ./target/release/bit-learn

# Run all tests once
BIT_CONFIG_PATH=/etc/bit BIT_TEST_PATH=./target/release ./target/release/bit-manager -o

# Install system-wide
cargo deb -p bit_manager
sudo dpkg -i target/debian/*.deb

# Enable as systemd service
sudo systemctl enable bit_manager
sudo systemctl start bit_manager

Components¶

bit-manager¶

The main test orchestrator that:

Loads test plugins dynamically
Schedules PBIT and CBIT tests
Manages test execution and logging
Provides systemd service integration

bit-learn¶

Interactive configuration generator that:

Detects system hardware (CPUs, disks, NICs, USB/PCI devices, sensors)
Prompts for test thresholds with sensible defaults
Auto-generates TOML configuration files
Discovers available interfaces (CAN, GPIO, serial ports)

bit-inspect¶

Test information tool that:

Lists all available tests
Shows detailed test metadata
Displays configuration values
Helps validate test setup

Test Types¶

Power-On Tests (PBIT)¶

Run once at system startup to verify hardware:

CPU core count validation
Disk health (SMART data)
Memory integrity
Peripheral detection (USB, PCI devices)
Network interface availability
Temperature sensors
Security configuration (SELinux/AppArmor, SSH, firewall)

Continuous Tests (CBIT)¶

Monitor system health at regular intervals:

CPU and memory utilization
Disk usage monitoring
Temperature monitoring
Network interface status
Process and service monitoring
Security policy enforcement
Log file analysis

Factory Tests (FBIT)¶

Manufacturing and production validation:

CAN bus loopback
Serial port loopback
GPIO loopback
USB device testing
SSD performance
Video device capabilities
Network throughput (TCP/iPerf)

Documentation Structure¶

Getting Started: Installation and setup guide
User Guide: How to run and configure tests
Test Reference: Detailed test documentation
Development: Creating custom tests
API Reference: Rust API documentation

System Requirements¶

Linux kernel 4.4 or later
Rust 1.70+ (for building from source)
systemd (optional, for service integration)
Hardware permissions for certain tests (CAN, GPIO, serial ports)
